TPS Wall Pack Full Cutoff, UL & DLC

All-in-one Wall Pack Light 120-277V Input Bronze Housing With photocell ready. The TPS All-In-One full-cutoff wall packs feature a sleek and modern architectural design that not only enhances the visual appeal of building exteriors but also optimizes light distribution. The precision-crafted optical lens allows for a broad distribution pattern, making it ideal for increased fixture spacing and achieving uniform illumination, ensuring a well-lit exterior space.

• Instant start, NO flickering, NO humming
• Power selectable and CCT selectable
• DLC Premium, UL Certified, IP65 rated, THD<20%, PF>0.95, Ra80, flicker free
• FCC Part 15, Part B, Class A standards qualified
• 0-10V dimmable driver, with 12V aux output available
• 6kV surge protection provided
• Ambient operating temperature: -40°C/-40°F to 50°C/122°F
• Heat sink design with heavy duty die-casting aluminum housing
• Pre-installed dusk-to-dawn photocell
• Delivers dark sky-friendly performance by eliminating unwanted sky glow and glare
• Applicable for building mount for exterior illumination
• Full cutoff design enhances the building's visual appeal while optimizing the effective distribution of functional lighting

WPCF-8DW-120PS-M1-BR - SpecSheet
